ODA Continues Italy Work Tour at IntelliCAD World 2019

oda logo

logo_itc_01_DarkSeveral members of the Open Design Alliance (ODA) team arrived in southern Italy after ODA DevCon last week in Milan to give an update on ODA technologies, including Drawings, BimRv, and IFC SDKs, and also the ODA Technology Stack.

Sergey Vishnevetsky, ODA Director of Development, commented that it was great to see new ODA features already implemented in IntelliCAD. Also he was happy to report that they had been working on common properties functionality thanks to ITC requests. Common data access to all supported ODA formats includes access to both the model tree and properties. The model tree structure is still in-progress, but common properties are in production currently.

buildingSMART

We also heard about ODA's strategic partnership with buildingSMART. This is exciting news for several reasons, one being that the ITC is in the process of transitioning to ODA IFC SDK for IntelliCAD's current IFC support.

Topics: IntelliCAD BIM ITC IntelliCAD World Conference ODA

IntelliCAD Technology in 2019 and 2020

i-Logo 3What's been happening lately with the IntelliCAD engine? And what's next?

Here's what we learned at IntelliCAD World 2019:

  • IntelliCAD 9.1 and 9.2 were released earlier this year. We saw demos of many new features that are trending as important for ITC members: digital signatures, new architectural entities, customizable start page, system variable monitor, STEP and IGES support, Overkill command, and many more.
  • BIM solutions for IntelliCAD: attach .rvt/.rfa and .ifc files as underlays and work with BIM data. Architectural objects are already in the mix too, and soon will even be exportable to .ifc files using ODA IFC libraries.
  • IntelliCAD Mobile is gaining new ITC member interest and the Special Interest Group is growing. IntelliCAD Mobile can view and navigate various file types: drawings (.dwg, .dwt, .dxf), Design Web Format (.dwf), Open COLLADA™ (.dae), and images (.png, .jpeg, .tiff, etc.). Many new features are being developed for the next mobile version, including plans for voice recording and more measurement tools.
  • Sneak peak at IntelliCAD 10 which is in development now, based on the latest ODA libraries. Specifically we got a look at geographic locations and new visual styles that will be available by integration with OpenGL ES2. Lots of other features coming up.
  • The latest version of ARTISAN was also demonstrated by Clive Davies of Pictorex. ARTISAN is a photorealistic renderer that is integrated with IntelliCAD and available for ITC member licensing.
Topics: IntelliCAD BIM ITC Mobile Platform ARTISAN IntelliCAD World Conference

IntelliCAD Technology Consortium Announces Release of IntelliCAD 9.2

IntelliCAD 9.2

Portland, OR, USA — The IntelliCAD Technology Consortium (ITC) today announced the release of IntelliCAD 9.2.

IntelliCAD 9.2 is a major release that includes many new features and improvements including: import and export IGES and STEP format files, delete and combine duplicate or overlapping entities using the Overkill command, use right-to-left fonts, choose from additional list types for multiline text, undo or redo a selected range of actions, thicken surfaces and meshes to convert them to three-dimensional solids (for IntelliCAD versions that support solids), and publish a drawing to the newly supported .dwf/.dwfx published format. You can also set up automatic publishing to create .pdf, .dwf, or .dwfx files when you save or close a drawing.

Selection includes a collection of new features. The new Selection Filter pane, similar to the Properties pane, displays all entities in a drawing and allows you to filter and select entities by layer, color, entity type, and linetype. Polygons, rectangles, and break lines have additional grips and properties for smart editing, and selection cycling is available which makes it easier to select entities that overlap.

For versions of IntelliCAD that work with BIM files, add elevation and section lines to models; draw curtain walls; draw detailing elements for wood, studs, joists, and track; and convert two-dimensional entities to walls and slabs.

For versions of IntelliCAD that open, save, and edit .dgn files in their native format, the supported command set continues to grow with 3DORBIT, ATTDEF, BASE, BROWSER, DDVPOINT, DRAWORDER, ELLIPSE, IMAGE, and IMAGEATTACH.

Technical users will also appreciate the new .NET wrappers for architectural objects.

David Lorenzo, ITC President, stated, “This second major release for 2019 provides exciting new features for our members, and continues to keep our command backlog clear so we can focus on refactoring core components with our remaining time this year.”

IntelliCAD 9.2 is supported on Microsoft® Windows® 10, Windows 8, Windows 7, and Windows Vista®, including 32-bit and 64-bit versions. IntelliCAD Mobile Viewer versions are available for Windows desktop, Google® Android™, Apple® macOS® and iOS.

Interested IntelliCAD users can contact ITC members to receive details about availability of IntelliCAD software.

Companies interested in more details about IntelliCAD and membership in the ITC should contact the ITC directly. For more information about IntelliCAD and the ITC, including case studies, please visit http://www.intellicad.org/.

About the IntelliCAD Technology Consortium

The IntelliCAD Technology Consortium is an independent, non-profit organization funded and directed by its members specifically for the development of the IntelliCAD technology. The IntelliCAD Technology Consortium licenses the IntelliCAD technology to its commercial members, who in turn market and sell applications based on IntelliCAD to their end users. Commercial members have access to the IntelliCAD source code, documentation, developer support, and more. The ITC is also a founding member of the Open Design Alliance, thereby contributing to interoperability in the engineering industry.

For additional ITC news and information, visit the company web site (http://www.intellicad.org/) or call 1-503-293-7655.


Topics: IntelliCAD DWG BIM ITC DGN CAD

Just Released: progeCAD 2020 Professional

progeCAD_box

progeCAD 2020 Professional is available now with enhancements for working with IFC BIM files, tool palettes for blocks and hatches, digital signatures for .dwg files, formulas in tables, additions to 3D printing, and upgrades to working with point cloud files .rcp/.rcs, .pcg, .isd, .xyz, .ply, and .las, .laz files. And much more.

progeCAD 2020 Professional is based on the IntelliCAD 9 engine and is designed for drawing in 2D and 3D: CAD field and concept sketch, electrical schematics, building construction, AEC architectural, civil, GIS, Topography, structural, mechanical and industrial engineering, and MCAD mechanical.

Topics: IntelliCAD BIM ITC CAD ProgeSOFT GIS

IntelliCAD 9.1 Delivers More BIM

IntelliCAD 9.1 BIM Railing

IntelliCAD's BIM technology keeps growing with each IntelliCAD release. IntelliCAD 9.1, released in March 2019, includes the ability to attach version 2019 RVT/RFA format files from Autodesk® Revit® and draw more AEC entities such as stairs, railings, and steel (in addition to the existing ability to draw walls, doors, windows, and slabs).

As with previous versions of IntelliCAD that work with BIM files, you can attach and import RVT/RFA format files and IFC (Industry Foundation Classes) format files.

IntelliCAD's BIM features are developed within a Special Interest Group (SIG) made up of ITC members who want to specifically advance IntelliCAD's BIM functionality. The BIM SIG works the same way as ITC's Mobile, DGN, and User Interface SIGs — just another way that ITC tailors its services to what their members need.

  • To learn more about the BIM Special Interest Group, see our website.
  • To learn more about the IntelliCAD 9.1 release, see the press release.
Topics: IntelliCAD BIM ITC CAD

IntelliCAD Technology Consortium Announces Release of IntelliCAD 9.1

IntelliCAD 9.1

Portland, OR, USA — The IntelliCAD Technology Consortium (ITC) today announced the release of IntelliCAD 9.1.

IntelliCAD 9.1 is a major release that includes many new features and improvements.

One of the new major capabilities is attaching digital signatures to .dwg files and validating them. Another is the new Block Editor that makes it easier to create and edit blocks. One more is creating palettes that contain blocks, similar to using a stencil for easily adding shapes to a drawing. There is also a new type of selection grip for users working with schematic drawings where precise scale or sizing is not required.

More IntelliCAD 9.1 features include: print and publish drawings directly to PDF, click keywords at the command prompt, use a Start Page when the program launches, single-click to hide many user interface items at once and increase the drawing area, synchronize viewports, convert to mesh, convert to surface, show and hide edges of three-dimensional entities, view and edit system variables in the new System Variables Manager, and much more.

For versions of IntelliCAD that work with BIM files, attach version 2019 .rvt/.rfa files and draw more AEC entities such as stairs, railings, and steel.

For versions of IntelliCAD that open, save, and edit .dgn files in their native format, users can now work with solids, hatches, aligned dimensions, fill mode, and more.

David Lorenzo, ITC President, stated, “Although the 9.1 release was accomplished in about half the time of a normal IntelliCAD release cycle, it is packed with new features. The depth and breadth of the commands in this short cycle shows how the consortium is growing. This 9.1 spring release provides exciting new features for our members, and it clears much of our command backlog so we can focus on refactoring core components and select key features with our remaining time this year.”

IntelliCAD 9.1 is supported on Microsoft® Windows® 10, Windows 8, Windows 7, and Windows Vista®, including 32-bit and 64-bit versions. IntelliCAD Mobile Viewer versions are available for Windows desktop, Google Android, Apple macOS and iOS.

Interested IntelliCAD users can contact ITC members to receive details about availability of IntelliCAD software.

Companies interested in more details about IntelliCAD and membership in the ITC should contact the ITC directly. For more information about IntelliCAD and the ITC, including case studies, please visit http://www.intellicad.org/.

About the IntelliCAD Technology Consortium
The IntelliCAD Technology Consortium is an independent, non-profit organization funded and directed by its members specifically for the development of the IntelliCAD technology. The IntelliCAD Technology Consortium licenses the IntelliCAD technology to its commercial members, who in turn market and sell applications based on IntelliCAD to their end users. Commercial members have access to the IntelliCAD source code, documentation, developer support, and more. The ITC is also a founding member of the Open Design Alliance, thereby contributing to interoperability in the engineering industry.

For additional ITC news and information, visit the company web site (http://www.intellicad.org/) or call 1-503-293-7655.


Topics: IntelliCAD DWG BIM ITC DGN CAD

ArCADiasoft Celebrates 20 Years

arcadiasoft_20years

ArCADiasoft is celebrating 20 years of creating construction applications that range from structural design to interior and installation design to energy performance of building calculations to building surroundings design. Over the years they have produced more than 100 products for architects and engineers.

ArCADiasoft is a member of the ITC and their flagship product, ArCADia BIM, is based on the IntelliCAD engine.

Congrats to ArCADiasoft on achieving the 20-year milestone!

Topics: IntelliCAD BIM ITC Architecture CAD Interior Design Construction ArCADiasoft

Just Released: CMS IntelliCAD 9.0 Premium Edition with BIM

cms_icad90

CMS IntelliCAD 9.0 includes support for working with BIM .ifc and .rvt/.rfa files, viewing mechanical entities, drawing construction lines, resetting and re-associating dimensions, and more.

CMS IntelliCAD 9.0 Premium Edition is a major release from ITC member CAD-Manufacturing Solutions. It is based on the IntelliCAD engine.

To learn more about CMS IntelliCAD 9.0, see the CMS news.

To learn more about how CMS benefits from ITC membership, see the ITC website.

Topics: IntelliCAD CMS BIM ITC CAD

Building with More ODA Technology

IntelliCAD platform

IntelliCAD has always — since its first release twenty years ago  been based on technology that is now governed and advanced by the Open Design Alliance (ODA). In the beginning the focus was on .dwg, but over the years, both technologies have seemed to outgrow their initial aim on replicating the .dwg file format (ODA) and replicating its end-user capabilities (ITC).

This point was not necessarily highlighted in Prague, but the link between ITC and ODA technology was mentioned throughout the conference with the nonchalant transparency that is commonplace among the IntelliCAD community.

  • IntelliCAD — Uses the latest ODA libraries.
  • BIM — Attach Autodesk® Revit® files as underlays, based on the ODA BIM component
  • Mobile — Based on ODA libraries.
  • Walls, windows, doors, slabs — Draw and edit architectural entities (new in IntelliCAD 9), based on the ODA Architecture component.
  • Smart meshes — Draw and edit lightweight 3D meshes (new in IntelliCAD 9), based on the ODA Facet Modeler.
  • Custom objects — Work with custom architecture, civil, and mechanical objects, based on ODA Architecture, Civil, and Mechanical components.

The ITC employs many components of ODA technology (including ODA source code), then customizes that technology according to the needs of their members. And that's exactly what ITC members do: they employ many components of ITC technology (including ITC source code), then customize that technology according to the needs of their end-users. It's a consistent business model from start to finish.

Topics: IntelliCAD CAD Platform BIM ITC Architecture Civil Mobile Platform Mechanical ODA

Twenty Years Current: IntelliCAD has BIM

IntelliCAD BIM

One big change in the last twenty years since IntelliCAD was first released is use of Building Information Modeling (BIM) drawings, which usually contain 3D models of buildings that can be used for visualization, design, analysis, and to generate building construction documents.

At IntelliCAD World 2018 we learned which BIM files IntelliCAD works with and what you can do with them:

  • RVT/RFA format — Drawing and family files from Autodesk® Revit®. Attach these files as underlays in IntelliCAD, then control visibility of floors and categories, snap to entities, and explode the underlay into primitives and meshes.
  • IFC format — Drawing files in the IFC (Industry Foundation Classes) format. Attach these files as underlays too, or import them in IntelliCAD to retain entities and convert construction and architectural entities to AEC entities.

There was a lot of talk about BIM at the conference. Some ITC members are attaching BIM underlays, exploding them, then retracing primitives to get walls and other building elements as data for their custom applications. More members are interested in the BIM Special Interest Group, and with more collaboration, development will advance at a faster pace. Members want access to BIM files, and like all things IntelliCAD, members drive the development direction.

For more details about the ITC and BIM:

Topics: IntelliCAD BIM ITC IntelliCAD World Conference
